22.5KVA Cummins Generator Set

More by user: sales
Created: 15th Oct 2012
Modified: 15th Oct 2012

22.5KVA Dongfeng Cummins Generator Set

Model No. KC-A001


Rating Power(KW/KVA)  16/20

Standby Power(KW/KVA) 18/22.5

Rating Voltage(V) 400/230

Rating Ammeter(A)29

Fuel Consumption(l/h)5.2

Dimension(LXWXH)(mm) 1600X830X1200

Weight(kg) 950

Engine : Cummins

Engine Model :4B3.9-G2

Prime Power(KW) 24

Standby Power(KW¡^27

Bore X Stroke(mm) 102×120

Number of Cylinder : 4 in line

Displacement(l) 3.9

Compression Ratio 16.5:1

Aspiration Type

Nature intake

Cooling Type

Water cooled with Radiator

Total Coolant capacity(l)18

Total oil capacity(l)9

Governing Type Electrics Governor

Alternator : ENGGA

Alternator Model EG160S-16N

Rating Voltage(V) 400/230

Rating Capacity(KW/KVA) 16/20Eff.% 82.37%

Power Factor 0.8 lagged

Exciting type

Brushless self-exciter

Voltage regulation ±1% , AVR

Enclosure ClassIP21

Class of Insulation H
